Characteristic of high strength polyester filament air slide fabric:
①The surface is smooth and flat, the size is stable and does not deform.
②Air slide fabric has good air permeability, uniform and stable airflow.
③Good tensile strength, heat resistance, wear resistance, corrosion resistance.
④Less energy consumption, long life, reliable operation,and minimal maintenance.
⑤Higher strength, wear resistance, lower elongation at break.
Model | Tensilestrength kg/40mm | Thickness /mm | Breathability /m³/㎡. min | Temperature | Weight /kg/㎡ |
CS5-6 | >500 | 6.0 | 3.5 | ≤180 | 4.65 |
CS4-5.5 | >500 | 5.5 | 3.7 | ≤180 | 4.3 |
CS4-5 | >450 | 5.0 | 4.3 | ≤180 | 4.0 |
CS3-4 | >450 | 4.0 | 4.6 | ≤180 | 3.6 |
