Material regulating gate is a kind of regulating and cutting gate developed by our company according to the demand of pneumatic conveying condition. It is widely used in pneumatic conveying system in building materials, metallurgy, mining, light industry, glass and other industries.
The material adjustment gate is made of high quality carbon steel, which is divided into two channels. The lower channel is the inflatable layer, the upper channel is the conveying material layer, and the middle is the breathable layer. The ical gate can adjust the gate opening, especially suitable for non-viscosity dry powder, fine particles, etc. With small energy consumption, no noise, no pollution, less maintenance, no resistance, easy operation, long and other service life.
Operational principle:
The material regulating gate is fed by the fan with low pressure and small capacity air through the air layer of the air port of the lower channel, and the gas is evenly sprayed upward through the boiling plate, encouraging the material to shift upward. When the material weight falls, the equipment installation slope produces displacement, which repeatedly causes the displacement of the material forward. The regulating gate is composed of the wire rod gate and seals. It is driven by the manual rotation of the hand wheel, so that the gate shifts with the screw rod, playing the role of arbitrary adjustment or cutting off.
Direction for use:
Before installation, please check whether the inner cavity of the gate is attached with debris. If the boiling board is damp. If the boiling board is damp, please replace it before installation, otherwise it will affect the use effect. Check whether the transmission part is flexible and reliable. The flange connections should be fitted with sealing gaskets before tightening the bolts.
During debugging, manually rotate the hand wheel, clockwise rotation for off, on the contrary, the operation can be blocked.
